基于CDD函数的ICT系统设计技术
-
爱游戏体育在线app使用方法 机械工程及自动化爱游戏体育在线app使用方法, 北京 100083 相关阅读
基金项目:
爱游戏体育在线app使用方法自然科学基金资助项目(50575015)
Design technique based on CDD function for industrial CT system
-
School of Mechanical Engineering and Automation, Beijing Univers ity of Aeronautics and Astronautics, Beijing 100083, China
-
摘要: 工业计算机层析成像(ICT,Industrial Computed Tomography)是一种先进的非接触式无损 检测技术,具有复杂精密、非通用和高成本的特点,需要根据用户的具体检测需求进行定制 开发,以降低系统研发风险和成本.为此,提出并研究了一种基于对比度-细节-剂量(CDD ,Contrast-Detail-Dose)函数的ICT系统设计技术框架.据此,推导了扇束三代二维ICT 系统基于CDD函数的设计平台,并完成了软件开发.该项技术包括基于CDD函数的计算机辅助 设计(CAD,Computer Aided Design)模块、扇束三代二维ICT成像数字仿真模块和CT图像 性能评定模块3部分.其输入参数是表征用户检测需求的初始设计参数,输出参数是满足用户 检测需求的最优解.初始设计参数首先进入CAD模块完成性能考核;如果满足要求,再进入仿 真模块完成仿真考核;最后,对仿真结果进行量化评定,得到设计参数对应的系统性能指标 .计算机仿真和工程系统开发结果验证了该设计技术的有效性.
-
关键词:
- 工业CT /
- 系统设计 /
- 对比度-细节-剂量函数 /
- 仿真 /
- 性能评定
Abstract: Industrial computed tomography(ICT) is an advanced, non-contact and non-destructive testing method. It is complicated, non-universal and expe ns ive. It is necessary to make the custom development to reduce the risk and the c ost. A kind of design technique frame based on the contrast-detail-dose(CDD) fu nction was proposed for the development of ICT system. According to this frame, t he design method for fan-beam 3rd generation two dimensional ICT(2D-ICT) was d ed uced and the corresponding software platform was implemented which is consisted of three parts. They are the computer aided design(CAD) part based on the CDD func tion, the simulation part and the performance evaluation part. The initial desig n parameters firstly entered the CAD part. They secondly entered the simulation part if they passed the CAD check. The simulation results were finally evaluated by the evaluation part. The validity of the proposed method was proved by the computer simulation and the example of the engineering development. -
[1] Hammersberg P. A theoretical model for determination of the optimal irradiation conditions for computerized tomography[J]. Insight, 1 995, 37(12):978-985 [2] Hammersberg P, Mangard M. Optimal computerized tomography performance Proceedings BB 67CD. Berlin:DGZfp, 1999:31-43 [3] Mangard M, Hammersberg P. Optimized detail detectability in computerized tomography[J]. Journal of X-ray Science and Technology,1998,8(1):51-73 [4] E1672-95,Standard guide for computed tomography system selection[S] [5] Cohen G,Dibicanca F A. The use of contrast-detail-dose evaluation of i mage quality in a computed tomographic scanner[J]. J Comput Assist Tomogr,197 9,3:189-195 [6] Kensuke S,Rideki K,Shinji Y. Theoretical prediction of X-ray CT image quality using contrast-detail diagrams[J]. IEEE Trans on Nucl Sci,1982,NS- 29:2115-2121 [7] Cohen G,Wagner L K,Amtey S R. Contrast-detail-dose and dose efficienc y analysis of a scanning digital and a screen-film-grid radiographic system . Med Phy,1981,8(3):358-367 [8] 傅健. X射线三代工业CT工程关键技术研究 . 北京:爱游戏体育在线app使用方法机械工程及自动化爱游戏体育在线app使用方法,2004 Fu Jian. Research on engineering techniques for X-ray generation III industr ial CT and its application . Beijing:School of Mechanical Engineering and A utomation, Beijing University of Aeronautics & Astronautics, 2004(in Chinese) [9] E1441-00,Standard guide for computed tomography(CT) imaging[S] . [10] Gore J C,Tofts P S. Statistical limitations in computed tomogra phy[J]. Phys Med Biol,1978,23:1176-1182 [11] E1570-93,Standard practice for computed tomography(CT) examination -
